The Signature Series.

The Signature Series is the flagship series of packaged chillers by JTS. Ranging from 3-120 tons, the Signature line boasts all the features of a custom chiller without the custom price tag.

The Signature Series models come standard with robust frame and siding, rigid piping, stainless steel tank, fully insulated piping/tank, variable capacity compressors, micro-channel condensers, stainless steel brazed plate evaporators, EC fan motors, electronic expansion valves and full display microprocessor-based controls making it the obvious choice for the demands of critical cooling applications. The Signature Series is modular and fully customizable for your specific needs.

Standard Air Cooled Closed Loop Chiller. 3-120 Ton Cooling Capacity.

 JTS hours of operation: Monday through Friday 7:00am - 4:30pm Mountain Standard Time

The Signature Series  3 Ton

Chilled Water Supply – 1″ NPT
Chilled Water Return – 1″ NPT
Makeup Water – 3/4″
Drain – 3/4″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 7.8
Fan FLA 1.4
Pump FLA 1.8
UNIT MCA 13.9
UNIT MOP 20
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 6.2
Fan FLA 1.4
Pump FLA 1.7
UNIT MCA 11.7
UNIT MOP 15
SCCR 5kA

Width – 36″
Length – 54″
Height – 59″
Reservoir – 20 Gallons
Weight (operating) – 1050 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 32,700 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-25%
Pump Qty – 1
Pump HP  – 0.75
Pump Performance  – 25 GPM @ 26 PSI
Compressor Qty  – 1
Compressor Type  -Digital Scroll
Fan Qty – 1
Fan Type – EC Axial
Airflow – 5000 CFM (Total)

Single Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  4 Ton

Chilled Water Supply – 1″ NPT
Chilled Water Return – 1″ NPT
Makeup Water – 3/4″
Drain – 3/4″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 17.9
Fan FLA 2.6
Pump FLA 3.6
UNIT MCA 27.4
UNIT MOP 40
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 7.8
Fan FLA 1.4
Pump FLA 1.8
UNIT MCA 13.9
UNIT MOP 20
SCCR 5kA

Width – 36″
Length – 54″
Height – 59″
Reservoir – 20 Gallons
Weight (operating) – 1050 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 45,100 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-25%
Pump Qty – 1
Pump HP  – 0.75
Pump Performance  – 25 GPM @ 26 PSI
Compressor Qty  – 1
Compressor Type  -Digital Scroll
Fan Qty – 1
Fan Type – EC Axial
Airflow – 5000 CFM (Total)

Single Air-cooled Refrigeration Circuit (3-10 Ton)
Dual Independent Air-cooled Refrigeration Circuits (10-60 Ton)
Self-Contained Pressurized System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
12 Months Parts & Labor Warranty
24/7 Customer Service & Support

Remote Condenser
Remote Panel
Water-Cooled Condenser
Ultra-Low Ambient Package
High Ambient Package
Variable Speed Pump
Seismic Certification
Cleanable Air Filter
Salt Water Packages
Make Up Water Valve
Control Interface
Hot Gas Bypass
Fluid Filter
Multiple Circuit Designs
Fixed Scroll Compressors

The Signature Series  5 Ton

Chilled Water Supply – 1″ NPT
Chilled Water Return – 1″ NPT
Makeup Water – 3/4″
Drain – 3/4″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 20.4
Fan FLA 2.6
Pump FLA 3.6
UNIT MCA 31.1
UNIT MOP 50
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 9.7
Fan FLA 1.4
Pump FLA 1.8
UNIT MCA 16.3
UNIT MOP 25
SCCR 5kA

Width – 36″
Length – 54″
Height – 59″
Reservoir – 20 Gallons
Weight (operating) – 1050 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 58,000 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-25%
Pump Qty – 1
Pump HP  – 0.75
Pump Performance  – 25 GPM @ 26 PSI
Compressor Qty  – 1
Compressor Type  -Digital Scroll
Fan Qty – 1
Fan Type – EC Axial
Airflow – 5000 CFM (Total)

Single Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  7 Ton

Chilled Water Supply – 1.5″ NPT
Chilled Water Return – 1.5″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 27.6
Fan FLA 2.6
Pump FLA 6.8
UNIT MCA 45.1
UNIT MOP 70
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 12.8
Fan FLA 1.4
Pump FLA 3.4
UNIT MCA 21.8
UNIT MOP 30
SCCR 5kA

Width – 42″
Length – 79″
Height – 76″
Reservoir – 57 Gallons
Weight (operating) – 1700 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 85,300 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-25%
Pump Qty – 1
Pump HP  – 2
Pump Performance  – 25 GPM @ 47 PSI
Compressor Qty  – 1
Compressor Type  -Digital Scroll
Fan Qty – 1
Fan Type – EC Axial
Airflow – 5000 CFM (Total)

Single Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  10 Ton

Chilled Water Supply – 1.5″ NPT
Chilled Water Return – 1.5″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 20.4
Fan FLA 2.6
Pump FLA 6.8
UNIT MCA 56.1
UNIT MOP 70
SCCR 5kA

 Electrical (Based on 460V/3PH)

Compressor RLA 17.9
Fan FLA 1.4
Pump FLA 3.4
UNIT MCA 33.7
UNIT MOP 50
SCCR 5kA

Width – 42″
Length – 79″
Height – 76″
Reservoir – 57 Gallons
Weight (operating) – 1800 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 116,000 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 2
Pump Performance  – 25 GPM @ 47 PSI
Compressor Qty  – 2
Compressor Type  -Digital Scroll
Fan Qty – 2
Fan Type – EC Axial
Airflow – 10,000 CFM (Total)

Single Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  15 Ton

Chilled Water Supply – 2″ NPT
Chilled Water Return – 2″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 27.6
Fan FLA 2.6
Pump FLA 9.6
UNIT MCA 78.3
UNIT MOP 100
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 12.8
Fan FLA 1.4
Pump FLA 4.8
UNIT MCA 37.4
UNIT MOP 50
SCCR 5kA

Width – 52″
Length – 79″
Height – 76″
Reservoir – 57 Gallons
Weight (operating) – 2400 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 170,600 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 3
Pump Performance  – 35 GPM @ 54 PSI
Compressor Qty  – 2
Compressor Type  -Digital Scroll
Fan Qty – 2
Fan Type – EC Axial
Airflow – 10,000 CFM (Total)

Single Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  20 Ton

Chilled Water Supply – 2″ NPT
Chilled Water Return – 2″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 33.3
Fan FLA 2.6
Pump FLA 9.6
UNIT MCA 112.7
UNIT MOP 150
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 17.9
Fan FLA 1.4
Pump FLA 4.8
UNIT MCA 59.1
UNIT MOP 80
SCCR 5kA

Width – 52″
Length – 79″
Height – 79″
Reservoir – 57 Gallons
Weight (operating) – 2500 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 232,000 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 3
Pump Performance  – 35 GPM @ 54 PSI
Compressor Qty  – 2
Compressor Type  -Digital Scroll
Fan Qty – 4
Fan Type – EC Axial
Airflow – 10,000 CFM (Total)

Dual Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  25 Ton

Chilled Water Supply – 2″ NPT
Chilled Water Return – 2″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 51.3
Fan FLA 6.4
Pump FLA 13
UNIT MCA 148.7
UNIT MOP 175
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 23.1
Fan FLA 3.2
Pump FLA 6.5
UNIT MCA 75.2
UNIT MOP 90
SCCR 5kA

Width – 68″
Length – 90″
Height – 89″
Reservoir – 57 Gallons
Weight (operating) – 2800 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 293,400 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 5
Pump Performance  – 80 GPM @ 46PSI
Compressor Qty  – 2
Compressor Type  -Digital Scroll
Fan Qty – 4
Fan Type – EC Axial
Airflow – 26,000 CFM (Total)

Dual Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  30 Ton

Chilled Water Supply – 2″ NPT
Chilled Water Return – 2″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 55.8
Fan FLA 6.4
Pump FLA 13
UNIT MCA 169.4
UNIT MOP 225
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 26.9
Fan FLA 3.2
Pump FLA 6.5
UNIT MCA 80.8
UNIT MOP 100
SCCR 5kA

Width – 68″
Length – 90″
Height – 89″
Reservoir – 57 Gallons
Weight (operating) – 2800 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 347,800 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 5
Pump Performance  – 80 GPM @ 46PSI
Compressor Qty  – 2
Compressor Type  -Digital Scroll
Fan Qty – 4
Fan Type – EC Axial
Airflow – 26,000 CFM (Total)

Dual Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  40 Ton

Chilled Water Supply – 2″ NPT
Chilled Water Return – 2″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 33.3
Fan FLA 9.8
Pump FLA 13
UNIT MCA 224.9
UNIT MOP 250
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 17.9
Fan FLA 4.9
Pump FLA 6.5
UNIT MCA 117.2
UNIT MOP 125
SCCR 5kA

Width – 68″
Length – 90″
Height – 89″
Reservoir – 57 Gallons
Weight (operating) – 3200 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 464,000 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 5
Pump Performance  – 80 GPM @ 46PSI
Compressor Qty  – 4
Compressor Type  -Digital Scroll
Fan Qty – 4
Fan Type – EC Axial
Airflow – 48,000 CFM (Total)

Dual Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  50 Ton

Chilled Water Supply – 3″ NPT
Chilled Water Return – 3″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 51.3
Fan FLA 9.8
Pump FLA 13
UNIT MCA 278.9
UNIT MOP 300
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 23.1
Fan FLA 4.9
Pump FLA 6.5
UNIT MCA 140.6
UNIT MOP 150
SCCR 5kA

Width – 68″
Length – 120″
Height – 89″
Reservoir – 83 Gallons
Weight (operating) – 4950 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 586,800 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 5
Pump Performance  – 130 GPM @ 44PSI
Compressor Qty  – 4
Compressor Type  -Digital Scroll
Fan Qty – 6
Fan Type – EC Axial
Airflow – 48,000 CFM (Total)

Dual Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets

The Signature Series  60 Ton

Chilled Water Supply – 3″ NPT
Chilled Water Return – 3″ NPT
Makeup Water – 3/4″
Drain – 1″ (Gravity drain acceptable)
Main Power – 3 conductors with ground (Refer to electrical data)
Digital Enable – 2 conductor 1-18 GA (Optional)
Alarm – 2 conductor up to 250 V/10A (Optional)

Electrical (Based on 230V/3PH)
Compressor RLA 55.8
Fan FLA 9.8
Pump FLA 13
UNIT MCA 318
UNIT MOP 350
SCCR 5kA

Electrical (Based on 460V/3PH)
Compressor RLA 26.9
Fan FLA 4.9
Pump FLA 6.5
UNIT MCA 151.2
UNIT MOP 175
SCCR 5kA

Width – 68″
Length – 120″
Height – 89″
Reservoir – 83 Gallons
Weight (operating) – 4950 lbs
Performance 45F LWT, 30% P.G. @ 100F AMBIENT – 695,600 BTU/HR
Operating Ambient -20F to 120F
Unloading Capacity – 100%-12.5%
Pump Qty – 2
Pump HP  – 5
Pump Performance  – 130 GPM @ 44PSI
Compressor Qty  – 4
Compressor Type  -Digital Scroll
Fan Qty – 6
Fan Type – EC Axial
Airflow – 72,000 CFM (Total)

Dual Air-cooled Refrigeration Circuit
For Use With Water or Water/Glycol
Self-Contained Pressurized Hydronic System
Stainless Steel Centrifugal Process Pump
Digital Scroll Compressor
Disconnect
Stainless Steel Brazed Plate Evaporator
Type L Copper Water Piping
Vertical Air Discharge
Manual Bypass Valve
Stainless Steel Reservoir
Expansion Tank
Closed-Cell Insulation
Refrigeration Isolation Valves
Liquid Line Solenoid Valve
Microprocessor Based Controller
Inlet/Outlet Pressure Gauges
Textured Powder Coated Cabinet
Make Up Water Valve
Liquid Level Warning
Flow Fault
NEMA4 Electrical Enclosure
Outdoor Rated
UL508a & UL1995 Listed
-20° To 120° F Operating Ambient
18 Months Parts & Labor Warranty
24/7 Customer Support

Remote Control Panel
Control Interface
Remote Condenser
Scroll Compressor
Hot Gas Bypass
Water-Cooled Condenser
Ultra-Low Ambient Package (-40°F)
Ultra-High Ambient Package (140°F)
Variable Speed Pump
Cleanable Air Filter
Fluid Filter
Make-up Water Valve
Salt Water Packages
Multiple Refrigeration & Hydronic Circuit Designs
Seismic Certified Models
Sound Blankets
